Whole of House Systems

World Class Safe Water Systems, For Town and Tank water supplies.

WHOLE HOUSE SYSTEMS

AlkaWay has whole house Safe Water Systems for both town and tank water

Large capacity whole house filter systems are ideal for removing sediment and chlorine when your home is connected to town water. Alternatively, if you are on tank water we offer a whole house system that effectively removes sediment, pathogens, bad tastes and colour.

AlkaWay Whole House Safe Water Systems feature Industry Standard 4½” Diameter x 20″ Long Filters for inline installation providing safe water to your whole house or business.

AlkaWay has three configurations available – two for town water and one for tank/natural source water situations. Other configurations can be ordered from AlkaWay according to your Whole House requirements. It is generally advised that these systems be installed by a registered plumber. The benefits and specification of each AlkaWay Safe Water System are listed below.

Our Whole House Options:

(we can also customise each system as required)

Town Water

Essential Safe Water System

The Essential Safe Water System provides safe, clean water for a medium to a large house with 2 or more bathrooms on town water. It contains two commercial-size 20” filters:
1 micron (Absolute rated)* Sediment Filter and
20-micron Radial Granular Activated Carbon (GAC) Cartridge Filter.
Each filter is enclosed in 20” filter commercial strength housing.

* An absolute 1-micron filter traps 99.9 % of particles of 1-micron and larger. For additional information refer to the definition section at the bottom of this page.

  • AlkaWay Whole House – Essential Safe Water System

    AUD $1,120.00 inc. GST
    Add to cart

Essential Safe Water System Benefits

  • Removes chlorine
  • Removes cysts such as Giardia
  • Removes sediment
  • Removes bad tastes
  • Removes colour
  • Removes odours
  • Volatile Organic Chemicals (VOCs)
  • Pesticides
  • Reduces/removes bacteria
  • Easy to install
  • Easy to maintain
  • NOTE: Doesn’t remove Fluoride. Fluoride can be mostly removed when used in conjunction with the UltraStream, the worlds most advanced water filter unit. The UltraStream purifies, alkalizes, ionizes and infuses the water with molecular hydrogen. It would ideally be added in the kitchen for drinking and cooking water.

Items Included

2 x Brackets,
8 x Screws and Washers,
2 x Liquid filled Pressure Gauges,
2 x 20″ Cartridge Casing,
1 x PLV (Pressure Limiting Valve),

1 x 20” 1 µm (Absolute Rating) Sediment & Bacteria Filter,
1 x 20” 20 µm Radial Granular Activated (GAC) Cartridge.

General Filter Specification

  • Filter is pleated polypropylene media to provide additional surface area for longer filter life and increased particle removal.
  • End caps, centre tubes and media are thermally bonded as one integral component for added strength and to provide superior end sealing.
  • Absolute rated* one micron filter media removes cyst-sized particles for safe, cyst-free drinking water.
  • Effective to reduce cysts (99% of Cryptosporidium and Giardia) though it will also reduce other contaminants such as sediment, dirt, turbidity (cloudy water), limescale, rust, sand, silt, and other common particulates down to the 1 micron level.
  • Low pressure drop, high dirt holding capacity, durable physical strength.
  • Cartridges are manufactured to comply with FDA listed materials for use in potable water and liquid food applications.

* An absolute 1 micron filter traps 99.9 % of particles of 1 microns and larger. For additional information refer to the definition section at the bottom of this page.

  • Filter media is coconut shell Radial Granular Activated Carbon (GAC).
  • Effectively reduces chlorine, Volatile Organic Chemicals (VOCs), and pesticides, hazardous chemicals, odour removal and taste improvement.
  • Low pressure drop, high dirt holding capacity, durable physical strength.
  • Cartridges are manufactured to comply with FDA listed materials for use in potable water and liquid food applications.

Optimal Safe Water System

The Optimal Safe Water System provides optimal safe water for a medium to a large house with 2 or more bathrooms on town water. This three filter system has superior sub-micron filter capacity and removes most heavy metals. The system contains three filters:
1 Micron (Absolute rated) Sediment Filter,
20 Micron Radial Granular Activated Carbon (GAC) Cartridge Filter, and Ultra-D Sub-Micron Filter.
Each filter is enclosed in a 20” filter commercial strength housing.

* An absolute 1 micron filter traps 99.9 % of particles of 1 microns and larger. For additional information refer to the definition section at the bottom of this page.

  • AlkaWay Whole House – Optimal Safe Water System

    AUD $1,595.00 inc. GST
    Add to cart

Optimal Safe Water System Benefits

  • Removes pathogens
  • Removes heavy metals
  • Removes taste and odour
  • Chemical and organics removal or reduction
  • Suitable for food and beverage industry for high purity water
  • Removes de-salivation for pre-filtration
  • Other high purity applications
  • Finer particle retention and filtration capacity (2 to 3-micron pore size comparable to a 0.02-micron size for virus and bacteria removal)
  • Higher loading capacity (up to 25 times greater)
  • Wider pH operating window (4-9pH)
  • Very low pressure drop (approximately 2 psi)
  • Easy to install
  • Easy to maintain
  • NOTE: Doesn’t remove Fluoride. Fluoride can be mostly removed when used in conjunction with the UltraStream, the worlds most advanced water filter unit. The UltraStream purifies, alkalizes, ionizes and infuses the water with molecular hydrogen. It would ideally be added in the kitchen for drinking and cooking water.

Items included

3 x Brackets,
12 x Screws and Washers,
2 x Liquid filled Pressure Gauges,
3 x 20″ Cartridge Casing,
1 x PLV (Pressure Limiting Valve),

1 x 20” 1 µm (Absolute Rating) Sediment & Bacteria Filter,
1 x 20” 20 µm Radial Granular Activated (GAC) Cartridge,
1 x 20″ Ultra-D Sub-micron Filter.

General Filter Specification

  • Filter is pleated polypropylene media to provide additional surface area for longer filter life and increased particle removal.
  • End caps, centre tubes and media are thermally bonded as one integral component for added strength and to provide superior end sealing.
  • Absolute rated* one micron filter media removes cyst-sized particles for safe, cyst-free drinking water.
  • Effective to reduce cysts (99% of Cryptosporidium and Giardia) though it will also reduce other contaminants such as sediment, dirt, turbidity (cloudy water), limescale, rust, sand, silt, and other common particulates down to the 1 micron level.
  • Low pressure drop, high dirt holding capacity, durable physical strength.
  • Cartridges are manufactured to comply with FDA listed materials for use in potable water and liquid food applications.

* An absolute 1 micron filter traps 99.9 % of particles of 1 microns and larger. For additional information refer to the definition section at the bottom of this page.

  • Filter media is coconut shell Radial Granular Activated Carbon (GAC).
  • Effectively reduces chlorine, Volatile Organic Chemicals (VOCs), and pesticides, hazardous chemicals, odour removal and taste improvement.
  • Low pressure drop, high dirt holding capacity, durable physical strength.
  • Cartridges are manufactured to comply with FDA listed materials for use in potable water and liquid food applications.
  • Cartridges are manufactured to compliance with NSF and FDA requirements.
  • Filter Media, consists of coated micro-glass fibres produced using a wet laid non-woven manufacturing technology. The base media is laminated between layers of spun-bond to provide both strength and pleat support.
  • Cartridges are manufactured to comply with FDA listed materials for use in potable water and liquid food applications.
  • Effectively reduces or removes the following pathogens:
    >99.99% viruses (polio, rotavirus, nor-virus, etc.)**
    >99.99% bacteria (e coli, legionella, pseudomonas, etc.)**
    >99.95% cysts (giardia, cryptosporidium, etc.)**
  • Effectively reduces or removes the following heavy metals:
    >95% Lead**
    >80% Ferrous Iron**
    >95% Arsenic V**
    >95% Cadmium**
    >85% Chromium**
    >75% Selenium**
    >60% Mercury
    **Tested by a certified laboratory BCS Laboratories INC. in the U.S. (testing was done at 6.5pH) June and July 2014
  • Effectively reduces or removes the following organic and inorganic chemicals:
    – Chlorine (carbon version)
    – Bromine (carbon version)
    – Iodine (carbon version)
    – VOCs (volatile organic compounds)
    – Polychlorinated biphenyl (PCBs) and Bisphenol A (BPA)
    – Residual pharmaceuticals

Tank Water

Natural Source Safe Water System

The Natural Source Safe Water System is designed for an entire medium to a large house with 2 or more bathrooms on tank water or most natural water sources

. This system has two filters:
1 x 1 Micron Sediment Filter and
Ultra-D Sub-Micron Filter. The filters are enclosed in 20” commercial strength housings.

  • AlkaWay Whole House – Natural Safe Water System

    Rated 5.00 out of 5
    AUD $1,095.00 inc. GST
    Add to cart

Natural Safe Water System Benefits

  • Designed specifically for natural source or tank water
  • Removes pathogens
  • Removes heavy metals
  • Removes taste and odour
  • Chemical and organics removal or reduction
  • Suitable for food and beverage industry for high purity water
  • Removes de-salivation for pre-filtration
  • Other high purity applications
  • Finer particle retention and filtration capacity (2 to 3-micron pore size comparable to a 0.02-micron size for virus and bacteria removal)
  • Higher loading capacity (up to 25 times greater)
  • Greater efficiency in salt, brackish and fresh water
  • Wider pH operating window (4-9pH)
  • Very low pressure drop (approximately 2 psi)
  • Easy to install
  • Easy to maintain
  • NOTE: Doesn’t remove Fluoride. Fluoride can be mostly removed when used in conjunction with the UltraStream, the worlds most advanced water filter unit. The UltraStream purifies, alkalizes, ionizes and infuses the water with molecular hydrogen. It would ideally be added in the kitchen for drinking and cooking water.

Items included

2 x Brackets,
8 x Screws and Washers,
2 x Liquid filled Pressure Gauges,
3 x 20″ Cartridge Casing,
1 x PLV (Pressure Limiting Valve),

1 x 20” 1 µm Sediment & Bacteria Filter,
1 x 20″ Ultra-D Sub-micron Filter.

Note: To maximise the filter life, we recommended regular tank cleaning to reduce the likelihood of sediment from the water tanks blocking up the filter prematurely, especially after a longer than a normal dry spell when the tanks are running low.

General Filter Specification

  • The filter is pleated polypropylene media to provide additional surface area for longer filter life and increased particle removal.
  • End caps, centre tubes and media are thermally bonded as one integral component for added strength and to provide superior end sealing.
  • 1-micron filter media removes cyst-sized particles for safe, cyst-free drinking water.
  • Effective to reduce cysts (99% of Cryptosporidium and Giardia) though it will also reduce other contaminants such as sediment, dirt, turbidity (cloudy water), limescale, rust, sand, silt, and other common particulates down to the 1-micron level.
  • Low-pressure drop, high dirt holding capacity, durable physical strength.
  • Cartridges are manufactured to comply with FDA listed materials for use in potable water and liquid food applications.
  • 1-micron filter traps 99% of particles of 1 microns and larger. For additional information refer to the definition section at the bottom of this page.
  • Filter Media, consists of coated micro-glass fibres produced using a wet laid non-woven manufacturing technology. The base media is laminated between layers of spun-bond to provide both strength and pleat support.
  • Cartridges are manufactured to comply with FDA listed materials for use in potable water and liquid food applications.
  • Effectively reduces or removes the following pathogens:
    >99.99% viruses (polio, rotavirus, nor-virus, etc.)**
    >99.99% bacteria (e coli, legionella, pseudomonas, etc.)**
    >99.95% cysts (giardia, cryptosporidium, etc.)**
  • Effectively reduces or removes the following heavy metals:
    >95% Lead**
    >80% Ferrous Iron**
    >95% Arsenic V**
    >95% Cadmium**
    >85% Chromium**
    >75% Selenium**
    >60% Mercury
    **Tested by a certified laboratory BCS Laboratories INC. in the U.S. (testing was done at 6.5pH) June and July 2014
  • Effectively reduces or removes the following organic and inorganic chemicals:
    – Chlorine (carbon version)
    – Bromine (carbon version)
    – Iodine (carbon version)
    – VOCs (volatile organic compounds)
    – Polychlorinated biphenyl (PCBs) and Bisphenol A (BPA)
    – Residual pharmaceuticals

Bore Water

Underground Safe Water System

Underground Safe Water System is designed for individual bores, as each bore is unique and may contain chemicals and micro-organisms that are potentially harmful. Some of these chemicals are naturally occurring (such as those present in soils and rocks) while others are a result of contamination. Bore water quality does change over time and it is not always possible to tell if bore water is contaminated or not.  We recommend having your bore water tested periodically, especially if you’re drinking or preparing food with the bore water.

We normally require laboratory test results at the bore and at the outlet of the water storage tank.  This data will help us customised your Underground Safe Water System for your bore water system.

Please contact our experts on 1800 268 469.

The UltraStream

AlkaWay Whole House Safe Water Systems are enhanced by the addition of an UltraStream. The UltraStream will filter out most fluoride whilst providing you with supercharged drinking water. The UltraStream is the world’s most advanced water filter unit. It purifies, alkalizes, ionizes and infuses the water with molecular hydrogen. These benefits add to those provided by the AlkaWay whole of house Safe Water Systems. The UltraStream would ideally be installed in your kitchen for drinking and cooking water. The UltraStream is available in Counter top and Undersink options.

Definitions

Nominal Rating

A nominal rating for a filter is an arbitrary value assigned by the filter manufacturer and is expressed in terms of a percentage retention of a given challenge media such as ISO standard test dusts or glass beads. The value may represent the percentage of the entire distribution of particles that is removed from the test fluid or the percentage of a specific sized particle. Nominal filtration ratings are often used when comparing the performance of depth and non-membrane filters.

Absolute Rating

An absolute rating is the size of the smallest particle retained by a filter with a stated efficiency, such as 99%, under defined test conditions. Absolute ratings are typically applied to membrane or high performance non-woven filters. With filter sizing as a general rule, the smaller the micron rating for a filter the better. However, there is a trade-off, flow capability usually drops off as the micron rating gets smaller, especially if the water has a lot of sediment.

Micron Rating

The average size of the openings between pieces of the filter media are represented in microns. For example, a 20 micron filter has larger openings than a 5 micron filter. Consequently, the 20 micron filter element will let larger particles pass through the filter than the 5 micron media would.
Bacteria range in size from 0.2 to 2 microns in width or diameter and from 1 to 10 microns in length for the non-spherical species, so a 1 micron filter will remove most bacteria and cysts.
If you are on municipal (town) water, the water has already been treated with chlorine, chloramines and/or fluoride to remove bacteria, so chances are you do not have a bacteria problem, unless there is a problem with the water pipes between the water reclamation plant and your home. Many customers purchase the 1-micron absolute for the kitchen because it can remove some pharmaceutical drugs too.
If you are on rain, river, and creek or bore water and have a bacteria problem, installing a 1 micron absolute rated water filter at the point of use will remove most of the bacteria (99.9%).

Any other questions?

If you have any additional questions you’d like to ask our team of product specialists or alkaline experts, please call us on 1800 268 469 or email our team at info@alkaway.com.au
